FORMODAL® 025X
cast plates • ultra fine metal structure
Specially for:
– tool making, mold making, model making
– semiconductor industry
– vacuum technology
– solar industry
Available forms:
– sheets
– plates
– cuttings in nearly all requested lengths, widths and thicknesses
– circular blanks
– rings
– shaped blanks as per drawing
– parts as per drawing
Special features of this material:
– Reduced and controlled hydrogen content
– Ultra fine metal structure
– Very good machinability
– Excellent corrosion resistance
– Good welding properties
– Low stress and dimensionally stable
Applications:
– Semiconductor industry
– Vacuum technology
– Solar industry
– Tool making, mold making and model making
– Blow molds and injection molds
– Coating tools
– Molds for elastomer materials
– Molds and heat-stressed parts
– Molds with welded construction
– Refrigeration technology
FORMODAL® 025X cast plates (aluminum data sheet)
| Thickness inches | Length x Width inches | Length x Width inches |
|---|---|---|
| 0.197″ – 23.62″ | 141.73″ x 64.96″ | 157.48″ x 86.61″ |
| 0.197″ – 23.62″ | 196.85″ x 115.35″ | 236.22″ x 86.61″ |
| Material attributes: | |
|---|---|
| Hydrogen content | Max. 0.01 fl oz H2 / 0.22 lb Aluminum |
| Grain size | Edge: max. 3.15 mil; core: max. 4.72 mil |
| Pore size | Single pore max. 1.97 mil, cluster size max. 9.84 mil |
| Porosity | Average porosity in % at position A-F (sketch); max. average porosity 0.15% |
